Чипсет : Intel C232 Chipset
Съвместими процесори : Support for Intel Xeon E3-1200 v5 processors/Intel Core processors/ Intel Pentium processors/Intel Celeron processors in the LGA1151 package, L3 cache varies with CPU
Памет : 4 x DDR4 DIMM sockets supporting up to 64 GB of system memory, Dual channel memory architecture, Support for DDR4 2133 MHz memory modules, Support for non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory modules
Multi-GPU Support : Support for 2-Way AMD CrossFire technology
Портове : 1 x PS/2 keyboard port, 1 x PS/2 mouse port, 2 x USB 2.0/1.1 ports, 4 x USB 3.0/2.0 ports, 1 x RJ-45 port, 6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In)
Слотове : 1 x PCI Express x16 slot, running at x16 (PCIEX16), 1 x PCI Express x16 slot, running at x4 (PCIEX4), 2 x PCI Express x1 slots (All of the PCI Express slots conform to PCI Express 3.0 standard.), 2 x PCI slots
Конектори : 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x M.2 Socket 3 connector 1 x SATA Express connector 6 x SATA 6Gb/s connectors 1 x CPU fan header 3 x system fan headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 1 x USB 3.0/2.0 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header 1 x Thunderbolt add-in card connector 1 x serial port header 1 x parallel port header 1 x Clear CMOS jumper
Дисков интерфейс : 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2/x1 SSD support), 1 x SATA Express connector, 6 x SATA 6Gb/s connectors, Support for RAID 0, RAID 1, RAID 5, and RAID 10
Аудио : Realtek ALC892 codec, High Definition Audio, 2/4/5.1/7.1-channel, Support for S/PDIF Out
LAN : Intel GbE LAN chip (10/100/1000 Mbit)
BIOS : 2 x 64 Mbit flash, Use of licensed AMI UEFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Форм фактор : ATX Form Factor; 30.5cm x 20.0cm Гаранционен срок : 36 месеца
